Brocade XBR-G6MIDR12PTPOD-32G BR-MIDRMFEB-01-Z software license for HD-G620-24-32G switch
read more
The Brocade G720 Switch is a Gen 7 switch with 64 ports in an ultra-dense 1U design. Delivering unmatched 64G performance and 50% lower latency compared to the previous generation,
read more
Compatible QDD-400G-ZRP-S 400G ZRP Optical Transceivers
read more
Kit contains two SFP+ modules that can be used as a pair to achieve operating data rate up to 25 Gbps for distances up to 15km on a single optical cable. SFP/ SFP+/ SFP28
read more
Kit contains two SFP+ modules that can be used as a pair to achieve operating data rate up to 25 Gbps for distances up to 15km on a single optical cable. SFP/ SFP+/ SFP28 Optical Transceivers
read more
12/24 Ports Compatible Brocade BR6510 Gen 5 Fiber Channel 1U Switch BR6510-24-8G-R/BR6510-12-8GR/BR6510-24-8GR Fiber Optical Switch Suitable For 57-1000117-01/57-1000027-01/57-0000080-01/57-0000088-01/57-0000089-01/57-1000487-01/57-0000089-01/57-1000488-01/57-1000262-01/57-1000489-01/XBR-000458/XBR-000258/XBR-000499/XBR-000498
read more
HOT-Pluggable TOP QSFP-DD 200G SR8 100m Optical Transceiver
The Topstar Technologies TOP-QSFP-200G-DD-SR8 is a Eight-Channel, Pluggable, Parallel, Fiber-Optic QSFP Double Density for 2x100 Gigabit Ethernet Applications. This transceiver is a high performance module for short-range multi-lane data communication and interconnect applications. It integrates eight data lanes in each direction with 8x25.78125Gbps bandwidth. Each lane can operate at 25.78125Gbps up to 70 m using OM3 fiber or 100 m using OM4 fiber. These modules are designed to operate over multimode fiber systems using a nominal wavelength of 850nm.
item no.:
200G QSFP-DD SR8 100brand:
Top-TransWarranty:
3 YearsCondition:
NewTemperature:
0-70Data Rate:
200GDistance:
100mWavelength:
850nmConnector:
LCApplications
¨ IEEE 802.3bm 100GBASE SR8
Description
The Topstar Technologies TOP-QSFP-200G-DD-SR8 is a Eight-Channel, Pluggable, Parallel, Fiber-Optic QSFP Double Density for 2x100 Gigabit Ethernet Applications. This transceiver is a high performance module for short-range multi-lane data communication and interconnect applications. It integrates eight data lanes in each direction with 8x25.78125Gbps bandwidth. Each lane can operate at 25.78125Gbps up to 70 m using OM3 fiber or 100 m using OM4 fiber. These modules are designed to operate over multimode fiber systems using a nominal wavelength of 850nm. The electrical interface uses a 76 contact edge type connector. The optical interface uses an 24 fiber MTP (MPO) connector. This module incorporates Topstar Technologies proven circuit and VCSEL technology to provide reliable long life, high performance, and consistent service.
prev :
TOPSTAR Compatible Cisco Brocade 400G QSFP-DD SR8 100m Optical Transceivernext :
Used Finisar FTCD1323E1PCL 400GBASE-LR8 QSFP-DD Optical Transceiver
Compatible 200G QSFP56 LR4 10km with Hot-pluggable QSFP56 for 200G Ethernet 200GBASE-LR4 Fibre Channel 5G Network single-mode fibers
Designed for 200G Ethernet 200GBASE-LR4 links over duplex single-mode fibers,200G QSFP56 LR4 10km optical module (GQS-SPO201-LR4C) supports transmission distance up to 10km using LWDM wavelengths of 1295.56nm, 1300.05nm, 1304.58nm, and 1309.14nm
Compatible 400G Ethernet And Fiber Channel 400G-ER8 40km SMF Optical Transceiver Industrial-Temperature For Data Centers 5G Network Optical Module
QSFP-DD optical module, QSFP-DD optical fiber module, QSFP-DD 200G optical module, QSFP-DD 200G optical fiber module, QSFP-DD 400G optical module, QSFP-DD 400G optical fiber module; currently QSFP28 optical module has four electrical channels. Each channel operates at 10Gbps or 25Gbps and supports 40G and 100G Ethernet applications.
Compatible 400G QSFP-DD FR8 PAM4 2km optical module Hot-pluggable QSFP-DD Duplex LC for 400G Ethernet 400GBASE-FR8 and 5G Network
Designed for 400G Ethernet 400GBASE-FR8 links over duplex single mode fibers, theTOPSTAR 400G QSFP-DD FR8 optical module (coming soon) supports transmission distance up to 2km using LWDM wavelengths (1273.55nm, 1277.89nm, 1282.26nm, 1286.66nm, 1295.56nm, 1300.05nm, 1304.58nm, 1309.14nm).
Compatible 200G QSFP56 FR4 2km Designed for 200G Ethernet 200GBASE-FR4 and Fibre Channel 5G Network transceiver module
QSFP-DD optical module, QSFP-DD optical fiber module, QSFP-DD 200G optical module, QSFP-DD 200G optical fiber module, QSFP-DD 400G optical module, QSFP-DD 400G optical fiber module; currently QSFP28 optical module has four electrical channels. Each channel operates at 10Gbps or 25Gbps and supports 40G and 100G Ethernet applications.
Compatible 200G QSFP56 ER4 40km 5G Network single-mode fibers transceiver module Duplex LC for 200G Ethernet 200GBASE-ER4 Fibre Channel
QSFP-DD optical module, QSFP-DD optical fiber module, QSFP-DD 200G optical module, QSFP-DD 200G optical fiber module, QSFP-DD 400G optical module, QSFP-DD 400G optical fiber module; currently QSFP28 optical module has four electrical channels. Each channel operates at 10Gbps or 25Gbps and supports 40G and 100G Ethernet applications.
Compatible Finisar FTCD1323E1PCL 400GBASE-LR8 QSFP-DD Optical Transceiver
Compatible Finisar FTCD1323E1PCL 400GBASE-LR8 QSFP-DD Optical Transceiver Data Rate (max):425 Gb/s，Protocol:400G Ethernet Compliant，Low End Case Temperature (°C):0，High End Case Temperature (°C):70，Diagnostics:Digital，Transmitter:8x LWDM DFB Laser，Receiver:PIN，Voltage Supply:3.3，Connector:LC，Wavelength:1310nm Band
Used Finisar FTCD1323E1PCL 400GBASE-LR8 QSFP-DD Optical Transceiver
Used Finisar FTCD1323E1PCL 400GBASE-LR8 QSFP-DD Optical Transceiver Distance:10 km，Data Rate (max):425 Gb/s，Protocol:400G Ethernet Compliant，Low End Case Temperature (°C):0，High End Case Temperature (°C):70，Diagnostics:Digital，Transmitter:8x LWDM DFB Laser，Receiver:PIN，Voltage Supply:3.3，Connector:LC，Wavelength:1310nm Band
TOPSTAR Compatible Cisco Brocade 400G QSFP-DD SR8 100m Optical Transceiver
TOPSTAR Compatible Cisco Brocade 400G QSFP-DD SR8 100m Optical Transceiver Hot-pluggable QSFP-DD form factor，8 channels full-duplex transceiver module，8x 850nm VCSEL array and PIN photo-detector array，Internal DSP CDR circuits on both receiver and transmitter channels，Compliant with QSFP-DD MSA, CMIS and IEEE 802.3cd 200GBASE-SR4，Data rate up to 425Gbps (8x 50G PAM4)，Reach up to 70m (OM3) or 100m (OM4) over MMF with FEC，Power consumption < 10W，MPO24 receptacle，Built-in digital diagnostic functions，Operating case temperature range from 0°C to 70°C，3.3V power supply voltage，RoHS compliant (lead free)
