Brocade XBR-G6MIDR12PTPOD-32G BR-MIDRMFEB-01-Z software license for HD-G620-24-32G switch
read more
The Brocade G720 Switch is a Gen 7 switch with 64 ports in an ultra-dense 1U design. Delivering unmatched 64G performance and 50% lower latency compared to the previous generation,
read more
Compatible QDD-400G-ZRP-S 400G ZRP Optical Transceivers
read more
Kit contains two SFP+ modules that can be used as a pair to achieve operating data rate up to 25 Gbps for distances up to 15km on a single optical cable. SFP/ SFP+/ SFP28
read more
Kit contains two SFP+ modules that can be used as a pair to achieve operating data rate up to 25 Gbps for distances up to 15km on a single optical cable. SFP/ SFP+/ SFP28 Optical Transceivers
read more
12/24 Ports Compatible Brocade BR6510 Gen 5 Fiber Channel 1U Switch BR6510-24-8G-R/BR6510-12-8GR/BR6510-24-8GR Fiber Optical Switch Suitable For 57-1000117-01/57-1000027-01/57-0000080-01/57-0000088-01/57-0000089-01/57-1000487-01/57-0000089-01/57-1000488-01/57-1000262-01/57-1000489-01/XBR-000458/XBR-000258/XBR-000499/XBR-000498
read more
item no.:
Brocade 57-1000262-0brand:
BrocadeWarranty:
1 YearTemperature:
0°C ~ 70°CData Rate:
16GDistance:
20kmWavelength:
1310nmConnector:
LC duplex| Brocade Transceiver Support Matrix | |||||||||||||||||
|
Gen7
|
Gen6
|
Gen5
|
|||||||||||||||
| Description | Manufacturing Part Number | Brocade Ordering Part Number | Brocade7X |
BrocadeFC64-48 |
BrocadeFC32-X7-48 | BrocadeG720 | BrocadeX6 | BrocadeFC32-64 | BrocadeFC32-48 | BrocadeG630 | BrocadeG620 | BrocadeG610 | BrocadeDCX8510 | Brocade6520 | Brocade6510 | Brocade6505 | |
| 64 FC SFP+ | SWL | 57-1000495-01 | XBR-000462/XBR-000463(1-pack) |
|
●
|
|
●
|
|
|
|
|
|
|
|
|
|
|
| Gen 7 FC QSFP+ | SWL | 57-1000481-01 | XBR-000420(1-pack) |
●
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8G FC SFP+ |
SWL | 57-1000117-01 | XBR-000163/XBR-000164(8-pack) |
|
|
|
|
|
|
|
|
|
|
●
|
●
|
●
|
●
|
| LWL-10km | 57-1000027-02 | XBR-000153/XBR-000172(8-pack) |
|
|
|
|
|
|
|
|
|
|
●
|
●
|
●
|
●
|
|
| ELWL-25km | 57-0000080-01 | XBR-000174(1-pack) |
|
|
|
|
|
|
|
|
|
|
●
|
●
|
●
|
●
|
|
| 10G FC SFP+ | SWL | 57-1000114-01 | XBR-000218(1-pack) |
|
|
|
|
|
|
●
|
●
|
●
|
|
●
|
●
|
●
|
|
| LWL-10km | 57-1000115-01 | XBR-000217(1-pack) |
|
|
|
|
|
|
●
|
●
|
●
|
|
●
|
●
|
●
|
|
|
| SWL | 57-1000492-01 | XBR-000418(1-pack) |
|
●
|
●
|
●
|
|
|
●
|
●
|
●
|
|
●
|
●
|
●
|
|
|
| LWL-10km | 57-1000493-01 | XBR-000417(1-pack) |
|
●
|
●
|
●
|
|
|
●
|
●
|
●
|
|
●
|
●
|
●
|
|
|
| 16G FC SFP+ | SWL | 57-0000088-01 | XBR-000192/XBR-000193(8-pack) |
|
|
|
|
|
|
●
|
●
|
●
|
●
|
●
|
●
|
●
|
●
|
| SWL | 57-1000487-01 | XBR-000492/XBR-000493(8-pack) |
|
|
●
|
|
|
|
●
|
●
|
●
|
●
|
●
|
●
|
●
|
●
|
|
| LWL-10km | 57-0000089-01 | XBR-000198/XBR-000199(8-pack) |
|
|
|
|
|
|
●
|
●
|
●
|
●
|
●
|
●
|
●
|
●
|
|
| LWL-10km | 57-1000488-01 | XBR-000498/XBR-000499(8-pack) |
|
|
●
|
|
|
|
●
|
●
|
●
|
●
|
●
|
●
|
●
|
●
|
|
| ELWEL-25km | 57-1000262-01 | XBR-000258(1-pack) |
|
|
|
|
|
|
●
|
●
|
●
|
●
|
●
|
●
|
●
|
●
|
|
| ELWEL-25km | 57-1000489-01 | XBR-000458(1-pack) |
|
|
●
|
|
|
|
●
|
●
|
●
|
●
|
●
|
●
|
●
|
●
|
|
| 4x16G FC QSFP+ | SWL | 57-1000294-01/02 | XBR-000245(1-pack) |
|
|
|
|
●
|
●
|
|
●
|
●
|
|
●
|
|
|
|
| SWL | 57-1000267-01 | XBR-000232(1-pack) |
|
|
|
|
|
|
|
|
|
|
●
|
|
|
|
|
| 2km | 57-1000310-01 | XBR-000255(1-pack) |
|
|
|
|
●
|
|
|
|
|
|
●
|
|
|
|
|
| 32G FC SFP+ | SWL | 57-1000333-01 | XBR-000212/XBR-000213(8-pack) |
|
|
|
|
|
|
●
|
●
|
●
|
●
|
|
|
|
|
| SWL | 57-1000485-01 | XBR-000412/XBR-000413(8-pack) |
|
●
|
●
|
●
|
|
|
●
|
●
|
●
|
●
|
|
|
|
|
|
| LWL-10km | 57-1000332-01 | XBR-000238/XBR-000239(8-pack) |
|
|
|
|
|
|
●
|
●
|
●
|
●
|
|
|
|
|
|
| LWL-10km | 57-1000486-01 | XBR-000438/XBR-000439(8-pack) |
|
●
|
●
|
●
|
|
|
●
|
●
|
●
|
●
|
|
|
|
|
|
| ELWL-25km | 57-1000355-01 | XBR-000278(1-pack) |
|
|
|
|
|
|
●
|
●
|
●
|
●
|
|
|
|
|
|
| ELWL-25km | 57-1000494-01 | XBR-000478(1-pack) |
|
●
|
●
|
●
|
|
|
●
|
●
|
●
|
●
|
|
|
|
|
|
| 4x32G FC QSFP+ | SWL | 57-1000351-01 | XBR-000275(1-pack) |
|
|
|
|
●
|
●
|
|
●
|
●
|
|
|
|
|
|
| SWL | 57-1000490-01 | XBR-000475(1-pack) |
●
|
|
|
|
●
|
●
|
|
●
|
●
|
|
|
|
|
|
|
| 2km | 57-1000480-01 | XBR-000285(1-pack) |
●
|
|
|
|
●
|
●
|
|
●
|
●
|
|
|
|
|
|
|
| Ethernet QSFP+ | 40GBASE-SR4 or 4x10GbE | 57-1000129-01 | XBR-40G-SR4-INT-0286 |
|
|
|
|
|
●
|
|
|
|
|
|
|
|
|
| 40GbE BiDi | 57-1000339-01 | XBR-40G-SR-BIDI-0287 |
|
|
|
|
|
●
|
|
|
|
|
|
|
|
|
|
| 100GBASE-SR4 or 4x25GbE | 57-1000326-01 | XBR-100G-SR4-0288 |
|
|
|
|
|
●
|
|
|
|
|
|
|
|
|
|
MAIN SPECS
| Brand | Brocade |
| Place of origin | China |
| Form Factor | SFP+ |
| Wavelength | 1310nm |
| Distance | 25KM |
| Data Rate (max) | 16G |
| Low End Case Temperature (°C) | 0℃ |
| High End Case Temperature (°C) | 70℃ |
| Power Supply | 3.3v |
| Connector | LC connector |
| Warranty | 1-year |
| Certificate | CE , ROHS , FCC |
| Compatible with | Brocade DCX 8510,6520,6510,6505,7840 |
| DDMI | Yes |
| Time of delivery | within 24hours |
| Package |
10 pc/anti-static box |
