Compatible 25G BiDi SFP28 LR 20Km industrial Single LC Hot-pluggable SFP28 transceiver module for 25G Ethernet and Fibre Channel 5G Network Optical Module

Designed for 25G Ethernet and CPRI/eCPRI links over simplex single-mode fiber,25G BiDi SFP28 LR 20km industrial optical modules (GBP-2733250-L2T, GBP-3327250-L2T) support transmission distance up to 20km.

Full-duplex transceiver module,Hot-pluggable SFP28 form factor,Compliant with SFP28 MSA standard,CWDM DFB laser and PIN photo-detector,Internal CDR on both Transmitter and Receiver channel,Compliant with CPRI/eCPRI specifications,Data rate up to 25.78Gbps,1270nm-Tx and 1330nm-Rx or 1330nm-Tx and 1270nm-Rx,Reach up to 20km on SMF,Low power consumption < 1.2W,Single LC receptacle,Operating case temperature range -40 to 85°C (I-temp),Single 3.3V power supply,RoHS-6 compliant (lead free)

  • item no.:

    25G BiDi SFP28 LR 20
  • brand:

    Top-Trans
  • Warranty:

    3 Years
  • Condition:

    New
  • Temperature:

    -40℃~+85℃
  • Data Rate:

    25Gb/s
  • Distance:

    20km
  • Wavelength:

    1270nm-Tx and 1330nm-Rx or 1330nm-Tx and 1270nm-Rx
  • Connector:

    duplex LC
product details

25G BiDi SFP28 LR 20km Optical Transceiver 5G Network Optical Module 25G Ethernet And Fiber Channel SMF Optical Transceiver Industrial-Temperature For Data Centers


Features

  • Full-duplex transceiver module
  • Hot-pluggable SFP28 form factor
  • Compliant with SFP28 MSA standard
  • CWDM DFB laser and PIN photo-detector
  • Internal CDR on both Transmitter and Receiver channel
  • Compliant with CPRI/eCPRI specifications
  • Data rate up to 25.78Gbps
  • 1270nm-Tx and 1330nm-Rx or 1330nm-Tx and 1270nm-Rx
  • Reach up to 20km on SMF
  • Low power consumption < 1.2W
  • Single LC receptacle
  • Operating case temperature range -40 to 85°C (I-temp)
  • Single 3.3V power supply
  • RoHS-6 compliant (lead free)


WHY CHOOSE US TOPSTAR
  • Professional testing equipments: Error Detector/ Industrial Oven/ Agilent Oscilloscope/ Digitizer/ WaveRunner for producing process. Cisco/ Juniper/ Brocade/ Alcatel-lucent/Huawei/ERICSSON/ Datacom etc. guarantee compatibility.
  • Specialized in developing and producing the most Hi-tech products like: 40G QSFP+/ 100G CFP/CFP2/CFP4 / QSFP28 / 25G SFP28 / 200G QSFP56 /400G QSFP DD/400G OSFP .  Every month sales qty transceivers  more than 10W pcs .
  • OEM Compatible  transceivers  have  3-year warranty , support 3 months unconditional  return , 1 year replacement  or repair . Brand transceivers  have 1 year warranty .
  • Stocks holds more than 200,000 transceivers at any one time for immediate delivery. Shenzhen sales center, Shenzhen OEM/ODM factory , Shenzhen  warehouse , HK warehouse  , USA  San Francisco  branch  to support fast service and shipment .
