Compatible Router 1900 Series 2.5G 1270-1610nm 80km CWDM DWDM SFP Transceiver

CWDM Transceiver
new products

SFP WDM Module CWDM 1.25G 80km
SFP WDM Module CWDM 1.25G 80km SFP WDM Module CWDM 1.25G 80km SFP WDM Module CWDM 1.25G 80km

Compatible Router 1900 Series 2.5G 1270-1610nm 80km CWDM DWDM SFP Transceiver

TOP-CWDM-XX-2.5-80 optical transceivers are designed for optical interfaces for data communications with single mode fiber(SMF).

The transceiver designs are optimized for high performance and cost effective to supply customers the best solutions for telecom applications.

  • item no.:

    TOP-CWDM-XX-2.5-80

  • lead time:

    1-3 working days

  • product orgin:

    China

  • brand:

    Top-Trans

  • shipping port:

    Shenzhen

  • payment:

    EXW

  • price range:

    1-10/42$

  • Warranty:

    3 Years

  • Condition:

    New

  • Temperature:

    0℃~70℃/ -5℃~85℃/ -20℃~85℃

  • Data Rate:

    2.5G

  • Distance:

    80km

  • Wavelength:

    CWDM

  • Connector:

    Dual LC
contact now
Datasheet
product details

Router 1900 Series 2.5G 1270-1610nm 80km CWDM DWDM SFP Transceiver

2.5G 80km CWDM DWDM SFP


Features

Up to2.5Gb/s data links

DFB laser transmitter and APD receiver

Upto80KMon9/125μmSMF

Hot-pluggable SFP footprint

Duplex LC/UPC type pluggable optical interface

Low power dissipation

Metal enclosure, for lower EMI

RoHS compliant and lead-free

Single+3.3Vpowersupply

Support Digital Diagnostic Monitoring interface

Compliant with SFF-8472

Case operating temperature:0°Cto+70°C


Applications

Switch to Switch Interface

Fast Ethernet

Switched Backplane Applications

Router/Server Interface

Other OpticalLinks


STANDARD

SFP+MSA Compliant

SFF-8472reversion9.5compliant

IEEE802.3-2005compliant

Telcordia GR-468-COREcompliant

FCC47CFRPart15,ClassBcompliant

FDA21CFR1040.10and1040.11,class1compliant

RoHS compliant


Professional Service

Fully testing in Error Detector/ Industrial Oven/ Agilent Oscilloscope/ Digitizer/ WaveRunner etc specialist testing equipment before shipment.





OEM& ODM:

Customized label and package , OEM and ODM service offered.


tags : Router 1900 Series 2.5G 1270-1610nm 80km CWDM CWDM DWDM Sfp Transceiver Cisco 2.5G 80km SFP 80km SFP Transceiver
