DS-X2-FC10G-ER

DS-X2-FC10G-ER Compatible 10G Fibre Channel X2 1550nm 40km DOM Transceiver Module

DS-X2-FC10G-ER Compatible 10G Fibre Channel X2 1550nm 40km DOM Transceiver Module is supported on a wide range of equipment. Such as 7600 WS-X6708-10G-3C, 7600 RSP720-10GE, 6500 WS-X6708-10G-3C, 4500 WS-X4516-10GE

item no.:
DS-X2-FC10G-ER
Temperature:
0 to 70°C
Data Rate:
10G
Distance:
40km
Wavelength:
1550nm
Connector:
SC duplex

contact now

Datasheet

product details

DS-X2-FC10G-ER Compatible 10G Fibre Channel X2 1550nm 40km DOM Transceiver Module

Features

Compatible with X2 MSA Rev2.0b
Support of IEEE 802.3ae 10GBASE-ER at 10.3125Gbps
Transmission Distance up to 40Km(SMF)
SC Receptacle 1550nm Cooled EA-DFB Laser
SC Duplex Optical Connector
Hot Pluggable 70-PIN Connector with XAUI Electrical Interface
Management and control via MDIO 2-wire interface
Power Supply : +5V, +3.3V, APS(+1.2V)
Diagnostic Optics Monitoring
Temperature Range: 0~ 70 °C
ROHS Compatible

tags : DS-X2-FC10G-ER DS-X2 10G 10G-ER X2 1550nm 40km 10G X2
