GLC-BX80-DA-I

GLC-BX80-DA-I Compatible 1000BASE-BX BiDi SFP 1550nm-TX/1490nm-RX 80km DOM Transceiver Module

GLC-BX80-DA-I Compatible 1000BASE-BX SFP Transceiver Module (SMF, 1550nm-TX/1490nm-RX, 80km, LC, DOM)

item no.:
GLC-BX80-DA-I
Warranty:
1 Year
Temperature:
0 to 70°C
Data Rate:
155M
Distance:
80km
Wavelength:
Tx1550/Rx1490nm
Connector:
LC simplex

contact now

Datasheet

product details

GLC-BX80-DA-I Compatible 1000BASE-BX BiDi SFP 1550nm-TX/1490nm-RX 80km DOM Transceiver Module

Features

Transceiver unit with independent
1550nmDFBLaser diode transmitter
In GaAsPIN photo diode receiver
Up to 155Mbps data rate operation
Up to 80KMon9/125μmSMF
Standard serial ID information compliant with SFPMSA
Digital Diagnostic Monitor Interface
Very low EMI and excellent ESD protection
+3.3V single power supply
RoHS compliant
Case operating temperature Commercial:0°Cto+70°C Extended:-10°Cto+80°C Industrial:-40°Cto+85°C

tags : SFP-155M-80km SFP Tx1490/Rx1550nm 80km 155M Tx1490/Rx1550nm 80km 155M 80km
