GLC-SX-MM

GLC-SX-MM Compatible 1000BASE-SX SFP 850nm 550m DOM Transceiver Module

GLC-SX-MM is supported on a wide range of equipment. Such as Nexus 9300 Series (Switch/Module

item no.:
GLC-SX-MM
Warranty:
1 Year
Temperature:
0 to 70°C
Data Rate:
1.25G
Distance:
550m
Wavelength:
850nm
Connector:
LC duplex

contact now

Datasheet

product details

GLC-SX-MM Compatible 1000BASE-SX SFP 850nm 550m DOM Transceiver Module

Features

FP laser transmitter and PIN photo-detector
Dual Data-rate of 1.25Gbps/1.0625Gbps Operation
Up to 550M transmission distance on 9/125μm SMF
Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
Digital Diagnostic Monitor Interface
Very low EMI and excellent ESD protection
+3.3V single power supply
Compatible with RoHS
Operating case temperature: Commercial: 0°C to +70°C Extended: -10°C to +80°C Industrial: -40°C to +85°C

tags : SFP-1.25G SFP-1.25G 550m 1.25G 550m 1.25G 850nm 550m 1.25G MM SFP 850nm 550m
