Original Alcatel (Nokia) compatible SFP-10G-SR-ALC SFP+ Module Optical Transceiver Module

Original Alcatel (Nokia) compatible SFP-10G-SR-ALC SFP+ Module ,+3.3V single power supply,CE, Class 1 FDA and IEC60825-1 Laser Safety Compliant, RoHS, SFF-8431, SFP MSA.

item no.:
SFP-10G-SR-ALC
brand:
Nokia
Warranty:
1 Year
Condition:
New
Temperature:
0-70
Data Rate:
10G
Distance:
300m
Wavelength:
850nm
Connector:
LC

contact now

product details

Descrption

Media Type:	Multi-Mode Fiber (MMF)
TX Wavelength:	850 nm.
RX Wavelenght:	850 nm.
Minimum Optical Budget:	4.6 dB
Maximum Distance:	300m
Supported Data Rate:	1.25-10.31 Gbps
Supported Applications:	10G Ethernet (10.31Gbps), Gigabit Ethernet (1.25 Gbps), STM-64 (9.95Gbps)
DDM/DOM:	Support
Temperature Range:	Standard 0°-70°C
Connectors:	Double LC
Tx Wavelength Bandwidth:	20 nm (840-860 nm)
Rx Wavelength Bandwidth:	20 nm (840-860 nm)
Minimum Transmitting Power:	-6.5 dB
Maximum Transmitting Power:	1 dB
Receiver Sensitivity:	-11.1 dBm
Receiver Overload:	-1 dBm
Dispersion:	110 ps/nm
Transmitter Type:	VSCEL Laser
Receiver Type:	PIN photodiode
Power:	+3.3V single power supply
Chipset:	MAXIM, MINDSPEED, SEMTECH
Compliance:	CE, Class 1 FDA and IEC60825-1 Laser Safety Compliant, RoHS, SFF-8431, SFP MSA
Transceiver Type:	SFP+

tags : SFP-10G-SR-ALC Original Alcatel（Nokia） Optical Transceiver Module 10G SFP+ 850nm 300m
