100G QSFP28 LR 100m

100G QSFP28 LR 100m

Used Finisar FTLC9152RGPL 100G 100m SWDM4 QSFP28 Optical Transceiver

Used Finisar FTLC9152RGPL 100G 100m SWDM4 QSFP28 Optical Transceiver

Distance:100 m，Data Rate (max):103.1 Gb/s，Protocol:100G Ethernet Compliant，Low End Case Temperature (°C):0，High End Case Temperature (°C):70，Diagnostics:Digital，Transmitter:4x SWDM VCSEL，Receiver:PIN，Voltage Supply:3.3，Connector:LC，Wavelength:850nm Band

item no.:
100G QSFP28 LR 100m
brand:
Finisar
Warranty:
1 Year
Condition:
New
Temperature:
0-70
Data Rate:
10G
Distance:
100m
Wavelength:
850
Connector:
LC

contact now

product details

Product Description:

Distance:100 m
Data Rate (max):103.1 Gb/s
Protocol:100G Ethernet Compliant
Low End Case Temperature (°C):0
High End Case Temperature (°C):70
Diagnostics:Digital
Transmitter:4x SWDM VCSEL
Receiver:PIN
Voltage Supply:3.3
Connector:LC
Wavelength:850nm Band

Product Feature:

Hot-pluggable QSFP28 form factor
Supports 103.1Gb/s aggregate bit rate
Power dissipation <3.5W
RoHS compliant
Commercial case temperature range of 0°C to 70°C
Single 3.3V power supply
Maximum link length of 75m/100m/150m on OM3/OM4/OM5 Duplex Multimode Fiber (MMF)
4x25Gb/s 850nm VCSEL-based transmitter
4x25G CAUI-4 electrical interface
Duplex LC receptacles
I2C management interface

tags : Finisar FTLC9152RGPL 100G 100m SWDM4 QSFP28 Optical Transceiver 100G QSFP28 LR 100m
