Compatible 200G QSFP56 LR4 10km with Hot-pluggable QSFP56 for 200G Ethernet 200GBASE-LR4 Fibre Channel 5G Network single-mode fibers

Designed for 200G Ethernet 200GBASE-LR4 links over duplex single-mode fibers,200G QSFP56 LR4 10km optical module (GQS-SPO201-LR4C) supports transmission distance up to 10km using LWDM wavelengths of 1295.56nm, 1300.05nm, 1304.58nm, and 1309.14nm

item no.:
200G QSFP56 LR4 10km
brand:
Top-Trans
Warranty:
3 Years
Condition:
New
Temperature:
-40℃～+85℃
Data Rate:
4X50Gb/s
Distance:
10km
Wavelength:
1295.56nm, 1300.05nm, 1304.58nm, and 1309.14nm
Connector:
duplex LC

contact now

product details

5G Network Optical Module 200G Ethernet And Fiber Channel 200G QSFP56 LR4 10km Optical Transceiver SMF Optical Transceiver Industrial-Temperature For Data Centers

Features

4 channels full-duplex transceiver module
Hot-pluggable QSFP56 form factor
4 channels cooled LAN-WDM EML transmitter and PIN ROSA
Compliant with QSFP56 MSA and IEEE 802.3bs 200GBASE-LR4
Data rate up to 212Gbps
Reach up to 10km on SMF
Low power consumption < 7W
Duplex LC receptacles
Operating case temperature range 0 to 70°C (C-temp)
Single 3.3V power supply
RoHS-6 compliant (lead free)

WHY CHOOSE US TOPSTAR

Professional testing equipments: Error Detector/ Industrial Oven/ Agilent Oscilloscope/ Digitizer/ WaveRunner for producing process. Cisco/ Juniper/ Brocade/ Alcatel-lucent/Huawei/ERICSSON/ Datacom etc. guarantee compatibility.
Specialized in developing and producing the most Hi-tech products like: 40G QSFP+/ 100G CFP/CFP2/CFP4 / QSFP28 / 25G SFP28 / 200G QSFP56 /400G QSFP DD/400G OSFP . Every month sales qty transceivers more than 10W pcs .
OEM Compatible transceivers have 3-year warranty , support 3 months unconditional return , 1 year replacement or repair . Brand transceivers have 1 year warranty .
Stocks holds more than 200,000 transceivers at any one time for immediate delivery. Shenzhen sales center, Shenzhen OEM/ODM factory , Shenzhen warehouse , HK warehouse , USA San Francisco branch to support fast service and shipment .
