Original Alcatel Nokia compatible 3HE10551AA 100G QSFP28 Module Optical Transceiver Module

For Nokia
new products

QSFP28 100G DWDM SR4 100m
QSFP28 100G DWDM SR4 100m

Original Alcatel Nokia compatible 3HE10551AA 100G QSFP28 Module Optical Transceiver Module

Original Alcatel Nokia compatible 3HE10551AA 100G QSFP28 Module Optical Transceiver Module

  • item no.:

    QSFP28 100G DWDM LR4

  • brand:

    Nokia

  • Warranty:

    1 Year

  • Condition:

    New

  • Temperature:

    0-70

  • Data Rate:

    10G

  • Distance:

    10km

  • Wavelength:

    DWDM

  • Connector:

    LC
contact now
product details

Descrption


Media Type:

Single-Mode Fiber (SMF)

Connectors:

Double LC

TX Wavelength:

LAN WDM 1310nm

RX Wavelenght:

LAN WDM 1310nm

Minimum Optical Budget:

6.6 dB

Maximum Distance:

10km

Supported Data Rate:

103.125 Gbps

Supported Applications:

100G Ethernet (103.125Gbps)

DDM/DOM:

Supported

CDR (Clock and Data Recovery) chip

Supported

Forward Error Correction (FEC):

Host FEC Supported

Transmitter Type:

EML LAN WDM TOSA

Minimum Transmitting Power:

Each Lane -4.3 dB

Tx Wavelength Bandwidth:

4 LAN WDM Seperated 1310 nm Lanes (15.66 nm 1294.53 – 1310.19nm) (L0 Tx center 1295.56nm, L1 Tx center 1300.05nm, L2 Tx center 1304.58nm, L3 Tx center 1309.14nm)

Maximum Transmitting Power:

Each Lane 4.5 dB

Average Launch Power (Min) Each Lane:

-4 dBm

Receiver Sensitivity:

Each Lane -8.6 dBm

Average Launch Power (Max) Each Lane:

4.5 dBm

Extinction Ratio (Min):

4 dB

Receiver Type:

PIN ROSA

Rx Wavelength Bandwidth:

4 LAN WDM Seperated 1310 nm Lanes (15.66 nm 1294.53 – 1310.19nm) (L0 Tx center 1295.56nm, L1 Tx center 1300.05nm, L2 Tx center 1304.58nm, L3 Tx center 1309.14nm)

Average Receiver Sensitivity (Min) Each Lane:

-10.6 dBm

Average Receiver Sensitivity (Max) Each Lane:

0 dBm

Receiver Overload:

3.3 dBm

Temperature Range:

Standard 0°-70°C

Storage Temperature:

-40° to 85°C

Relative Humidity:

0 to 85%

Power Consumption:

≤3.5W

Power:

+3.3V

Chipset:

Macom, Sumitomo, Samtech, Oclaro, Avago, II-IV

Compliance:

Class 1 FDA, IEC60825-1 Laser Safety Compliant, IEEE 802.3ba 100GBASE-LR4, IEEE 802.3bm, RoHS-6, CE, QSFP28 MSA, SFF-8636, SFF-8665




tags : QSFP28 100G LR4 10km Original Alcatel（Nokia） Optical Transceiver Module 100GBASE-LR4 QSFP28
