Type B Plenum MTP To MTP Fiber Patch Cable 10M 8 Fibers OM4 Multimode

MTP FiberShield Specifications

8 Fiber Multimode (OM4) MTP Fiber Cable w/FiberShield with MTP(Female)-MTP(Female) connectors. Use this 5 Meter (Approx. 15ft) for 40G 50/125 (OM4) fiber optic links Type: For 40G Networks - Fiber optic cable for connection between two 40G QSFP+ transceivers with MTP/MPO interfaces or other 10G/40G network links. MTP Polarity Method B (Cross-Connect) - Key-up to Key-up (Polarity A or C optional), MTP-MTP.

Topstar's 8 fiber MTP cables feature our new and exclusive FiberShield design. The FiberShield structure employs three times (3x) the amount of the PVC jacket and DuPont Kevlar to protect the multitude of delicate optical fibers located inside the cables. This ruggedized cable structure results in a flexible yet robust 4.5mm MTP cable that is 5x stronger than the standard 3.0mm cable.

  • item no.:

    PT-8OM4MTP-C10
  • brand:

    Top-Trans
  • Warranty:

    1 Year
  • Condition:

    New
  • Distance:

    10m
product details


1m MPO Female to MPO Female OM3 Multimode Trunk Cable 12 Fibers Type B Plenum OFNP Aqua


MPO Female to MPO Female OM3 Multimode Trunk Cable

MPO trunk cable, a cost-effective alternative to time-consuming field termination, is designed for high-density fiber patching in data centers which need space saving and reduce cable management troubles.  it is optimized for 40G QSFP+ SR4/CSR4, 100G QSFP28 SR4 optics direct connection and high-density data center applications.

  • Cable Typle:12 core
  • Link way:Method A(1 VS 1) or Method B(1 VS 12) default Method B(1 VS 12), Please note the selection.
  • MPO male with pins, MPO female without pins
  • Fiber Type:OM3
  • Each MPO/MTP fiber cable has passed the test of Insertion Loss & Return Loss, 3D Interferometer, End-face Inspection, and Polarity Check in the factory, ensure complies and exceeds industry standards.


Fiber Type OM3 50/125um
Wavelength 850/1300nm
10G Ethernet Distance 300m at 850nm
40/100G Ethernet Distance 100m at 850nm
Polish Type UPC to UPC
Minimum Bend Radius 7.5mm
Attenuation at 850nm ≤2.3 dB/km
Attenuation at 1300nm
≤0.6 dB/km
Installation Tensile Load 66N
Tensile Strength (Long/Short Term) 80N/240N


10Gb 50/125 Multimode OM3 MPO Fiber Optic Trunk Cable (12 Fiber, MPO Female, Type B, LSZH, Aqua)
The requirements for data center infrastructures are increasing as the rapid growth in worldwide IT usage continues. As an experienced and innovative fiber optic cable manufacturer, Topstar supplies complete MPO trunk fiber optic cabling solutions for high-density optical connectivity in the modern data center. Compared with the classical fiber optic cabling solutions, this high-density fiber optic solution offers higher flexibility and space-saving while supporting very high data rates, such as 10-Gigabit, 40-Gigabit Ethernet and 100-Gigabit Ethernet.


Topstar's PT-12OM3MPO-10M is a factory pre-terminated 50/125 Multimode OM3 MPO trunk cable, offering the user the advantage of consistent quality, much faster installation, and simpler cable management. The MPO fiber optic trunk cable is manufactured with multiple, 12-strand MPO female connectors and 12 core OM3 fiber cables. The trunk cable conforms to Method B (Cross-Connect) polarity, and the MTP® connector is available upon request. This OM3 MPO trunk cable is suitable for use in 40G QSFP SR4 transceivers, 100G QSFP28 SR4 connections.
