Pluggable Compatible Juniper DWDM QSFPP-40GBASE-LR4 40GE QSFP+ LR4 Optics module

item no.:
40G QSFP+ LR4 10km
brand:
Top-Trans
Warranty:
1 Year
Condition:
New
Temperature:
0-70
Data Rate:
40G
Distance:
10km
Wavelength:
DWDM
Connector:
LC/PC

contact now

product details

Product Description:

Transceiver Type:QSFP+
Connector:LC
Monitoring Available:Yes
Standard: 40GBASE-LR4
Standards compliance (Ethernet/OTN Standard, for e.g. 100GBASE-LR4:)IEEE 802.3ba-2010
Transmitter wavelengths (range)
1264.5 through 1277.5 nm
1284.5 through 1297.5 nm
1304.5 through 1317.5 nm
1324.5 through 1337.5 nm
Transmitter output power, each lane (minimum):–7 dBm
Transmitter output power, each lane (maximum):2.3 dBm
Receiver input power, each lane (minimum):–13.7 dBm
Receiver input power, each lane (maximum):2.3 dBm
Cable type:Single mode
Distance:9/125 SMF cable, 10 km
Operating Temperature (range):0° C to 70° C
Storage temperature:–40° C to 85° C
